Specifications
Brand: HPE
MPN: 647592-001
Option Part Number: 647594-B21
Spare Part Number: 647592-001
General
Device Type: Network Adapter
Form Factor: Plug-in card
Interface (Bus) Type: PCI Express 2.0 x4
PCI Specification Revision: PCIe 2.0
Networking
Ports: Gigabit Ethernet x 4
Connectivity Technology: Wired
Cabling Type: Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
Data Link Protocol: 10Mb LAN, 100Mb LAN, GigE
Data Transfer Rate: 1 Gbps
Remote Management Protocol: SNMP
Status Indicators: Port transmission speed, link/activity
Features: Jumbo Frames support, PXE support, Large Send Offload (LSO)
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.3az
Processor / Memory
Processor: 1 x BCM5719 - Broadcom
RAM: 276 MB
Software / System Requirements
OS Required: SuSE Linux Enterprise Server 11, Microsoft Windows Server 2008 R2, Microsoft Windows Storage Server 2008 Embedded, SuSE Linux Enterprise Server 10, Microsoft Windows Server 2008 Enterprise, Microsoft Windows Server 2008 Standard, Microsoft Windows Web Server 2008, Microsoft Windows Server 2008 Enterprise x64 Edition, Microsoft Windows Server 2008 Standard x64 Edition, Microsoft Windows HPC Server 2008, Microsoft Windows Server 2008 (32/64-bits), Microsoft Windows Small Business Server 2011 Essentials, Oracle Solaris 10, Microsoft Windows Small Business Server 2011, Red Hat Enterprise Linux 6.1, Red Hat Enterprise Linux 5.7
Miscellaneous
Compliant Standards: FCC Class B certified, UL, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class B, FCC Part 15, RoHS, ICES, VCCI V-3 Class B ITE
Dimensions & Weight
Depth: 4.6 in
Height: 3 in
Environmental Parameters
Min Operating Temperature: 32 °F
Max Operating Temperature: 131 °F
Humidity Range Operating: 10 - 90% (non-condensing)
Expansion / Connectivity
Interfaces: 4 x 1000Base-T - RJ-45
Compatibility Information
HPE ProLiant DL360p Gen8, DL360p Gen8 Base, DL360p Gen8 CMS, DL360p Gen8 Entry, DL360p Gen8 High Performance, DL360p Gen8 Performance
