HP DL380 GEN10

Technical specifications HPE ProLiant DL380 Gen10 server
Processor type Intel
Processor family Intel® Xeon® Scalable 8100/8200 series, Intel® Xeon® Scalable 6100/6200 series, Intel® Xeon® Scalable
5100/5200 series, Intel® Xeon® Scalable 4100/4200 series, Intel® Xeon® Scalable 3100/3200 series
Processor number 1 or 2
Processor core available 4 to 28 core, depending on model
Processor cache 8.25 - 38.50 MB L3, depending on processor model
Processor speed 3.9 GHz, maximum depending on processor
Expansion slots 8, for detailed descriptions reference the QuickSpecs
Maximum memory 3.0 TB with 128 GB DDR4, depending on processor model
6.0 TB with HPE 512GB 2666 Persistent Memory Kit, depending on processor model
Memory, standard 3.0 TB (24 X 128 GB) LRDIMM
6.0 TB (12 X 512 GB) Persistent Memory
Memory slots 24 DIMM slots
Memory type HPE DDR4 Smart Memory with optional Intel® Optane™ persistent memory 100 series for HPE, depending
on processor model selected. Intel Optane Persistent Memory for HPE only supported on select 2nd
Generation Intel Scalable Series Processors, to include: 82xx, 62xxR, 62xx, 52xxR, 52xx series processors,
and the 4215R and 4215 processors.
System fan features Hot-plug redundant fans, standard
Network controller HPE 1 Gb 331i Ethernet adapter 4-ports per controller and/or optional HPE FlexibleLOM, depending on
model
Storage controller 1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a and/or 1 HPE Smart Array P816i-a and/or 1
HPE Smart Array E208i-a, depending on model
Product dimensions (imperial) 17.54 x 28.75 x 3.44 in
Weight 32.6 lb
Infrastructure management HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download)
(standard) HPE iLO Advanced, and HPE OneView Advanced (optional
requires licenses)
Warranty 3/3/3 - Server Warranty includes three years of parts, three years of labor, three years of onsite
support coverage. Additional information regarding worldwide limited warranty and technical support is
available at: http://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service
coverage for your product can be purchased locally. For information on availability of service
upgrades and the cost for these service upgrades, refer to the HPE website at
http://www.hpe.com/support
Drive supported 8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD
2 M.2 SATA SSD standard on primary riser, depending on configuration
6 SFF rear drive optional or 3 LFF rear drive optional and 2 SFF or 2 Dual UFF rear drive optional
20 SFF NVMe optional
NVMe support via Express Bay will limit maximum drive capacity
