DELL PowerEdge R730

Feature PowerEdge R730 technical specification
Form factor 2U rack
Dimensions H: 8.73 cm (3.44 in), W: 44.40 cm (17.49 in), D: 68.40 cm (26.92 in)
Processor Intel® Xeon® processor E5-2600 v4 product family
Processor sockets 2
Cache 2.5MB per core; core options: 4, 6, 8, 10, 12, 14, 16, 18, 22
Chipset Intel C610 series chipset
Memory1 Up to 3TB (24 DIMM slots): 4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s
I/O slots Up to 7 x PCIe 3.0 plus dedicated PERC slot
RAID controllers Internal controllers: PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P
External HBAs (RAID): PERC H830
External HBAs (non-RAID): 12Gbps SAS HBA
Drive bays Internal hard drive bay and hot-plug backplane:
Up to 16 x 2.5" HDD: SAS, SATA, nearline SAS SSD: SAS, SATA
Up to 8 x 3.5" HDD: SAS, SATA, nearline SAS SSD: SAS, SATA
Maximum internal storage1 HDD: SAS, SATA, nearline SAS SSD: SAS, SATA
16 x 2.5" – up to 29TB via 1.8TB hot-plug SAS hard drives
8 x 3.5" – up to 64TB via 8TB hot-plug NL SAS hard drives
Embedded NIC 4 x 1GbE, 2 x 10+2GbE, 4 x 10GbE NDC
Power supplies Titanium efficiency 750W AC power supply; 1100W DC power supply; Platinum efficiency 495W, 750W,
1100W AC power supply;
Availability ECC memory, hot-plug hard drives, hot-plug redundant cooling, hot-plug redundant power, internal dual SD module, single
device data correction (SDDC), spare rank, tool-less chassis, support for high availability clustering and virtualization,
proactive systems management alerts, iDRAC8 with Lifecycle Controller
Remote management iDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade)
8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
Systems management IPMI 2.0 compliant
Dell OpenManage Essentials
Dell OpenManage Mobile
Dell OpenManage Power Center
Dell OpenManage Integrations:
• Dell OpenManage Integration Suite for Microsoft®
 System Center
• Dell OpenManage Integration for VMware®
 vCenter™
Dell OpenManage Connections:
• HP Operations Manager, IBM Tivoli® Netcool®
 and CA Network and Systems Management
• Dell OpenManage Plug-in for Oracle® Database
 Manager
